Parachute type air lift bag

Matchau is the professional manufacturer of underwater air lifting bags in China.
Matchau parachute type lifting bags are designed with water drop shaped units for supporting and lifting loads from any water depth.Its single point attachment is ideal for lightening underwater structures such as pipes, and their admin application is used to bring sunken objects and other loads from the seabed to surface.
Our underwater lifting bags are manufactured by heavy duty polyester cloth coated with PVC. All quality and load-assured strops and connectors are traceable.
  • PLB
  • MATCHAU
Availability:
Quantity:

Models and Specifications:

                  Type

   Model

 Lifting Capacity

      Dimension

            (m)

Approx

Weight

           Kgs

Diameter

Height

   Kgs

Commercial Lifting Bags

 PLB-25L

            25

    0.4

   0.8

     2

 PLB-50L

            50

    0.5

   0.9

     3

PLB-100L

          100

    0.6

   1.1

     4

PLB-250L

          250

    0.8

     2

     5

PLB-500L

          500

    1.2

     2

     8

Professional Lifting Bags

  PLB-1T

        1,000

    1.3

   2.4

    15

  PLB-2T

        2,000

    1.8

   2.6

    23

  PLB-3T

        3,000

    1.6

    4

    35

  PLB-5T

        5,000

     2

   3.8

    42

  PLB-6T

        6,000

    2.3

   3.4

    52

  PLB-8T

        8,000

    2.4

   3.6

    60

 PLB-10T

       10,000

    2.5

   4.6

    80

 PLB-15T

       15,000

     3

   4.3

   120

 PLB-20T

       20,000

    3.4

   5.6

   160

 PLB-25T

       25,000

    3.9

    6

   180

 PLB-30T

       30,000

     4

   6.3

   210

 PLB-35T

       35,000

    4.2

   6.5

   230

 PLB-50T

       50,000

     5

   7.5

   300
